TGS-330-350-P72

TGS-330-350-P72

Cell type Polycrystalline(156.75*156.75mm)
Number of cells 72
Dimensions 1956*992*40mm
Weight 22.8kg
Glass 3.2mm tempered glass,high transmission(>94%),anti-reflective coating.
Frame Anodized aluminium alloy
Junction box IP68 rated(3 by pass diodes)
Cable 4mm²,900mm (+) 900mm (-) ; length can be customized.
Connector MC4 or MC4 compatible
Max front load(e.g.:snow) 5400 Pa
Max back load(e.g.:wind) 2400 Pa
